Htp-300y Submersible Pressure Transmitter Ip68 4-20ma Rs485 0-10v 316l Stainless Steel Hydrostatic Level Sensor

1,NOTEDue to page limitations, some configurations may not be listed. Please contact us .Default Configuration:Cable Length: 1.5MPower Supply: DC24VSignal Output: 4-20mAProtection Rating: IP68Customizable Options:Power Supply: 9~24VDCSignal Output Types: 4-20mA, 0-5V, 0-10V, RS485Cable Length: 10M, 15M, 20M, etc.For custom requirements, please contact us2.ParametersParameterDetailsModelHTP-300YMeasurement Range-100kPa...0~1kPa...100MPaOutput Signal4-20mA, 0-5V, 0-10V, RS485Supply Voltage9-24VDC, 3.1-5VPressure TypeGauge, Absolute, SealedAccuracy±0.5%FS (typical), ±0.2%FS, ±0.1%FSCompensated Temperature-10~70°COperating Temperature-20~80°CZero Temp Drift±0.5%FS (max)Sensitivity Temp Drift±0.5%FS (max)Overpressure2x (10MPa), 1.5x (>25MPa)Vibration Resistance20G (20-5000Hz)Sampling Rate2400 samples per secondProtection LevelIP68Material CompatibilityCompatible with 316L stainless steelEnclosure MaterialAluminum alloy, polyurethane cableResponse Time10msInsulation Resistance100M/250VDC3.FeaturesHigh AccuracyAchieves up to ±0.1%FS precision for dependable and accurate pressure readings.Customizable ConfigurationsFlexible options for power supply (9~24VDC) and signal outputs (4-20mA, RS485) to meet various requirements.Durable and ReliableConstructed with 316L stainless steel and rated IP68 for optimal performance in tough environments.Wide Temperature CompatibilityOperates efficiently in conditions with a temperature range of -20°C to 80°C.Fast Response TimeOffers a rapid 10ms response for real-time pressure monitoring.4.ApplicationsConstant-pressure water supply systemsHydraulic systemsLiquid level monitoringEnergy production5.FAQsQ: Can the cable length be customized?A: Yes, cable lengths such as 10m, 15m, and 20m can be customized.Q: What types of media are supported?A: It is compatible with fluid media that do not corrode 316L stainless steel.Q: What is the device's protection rating?A: The device is IP68-rated, ensuring excellent resistance to water and dust.Origin : Mainland ChinaMeasurement Range : -100kPa...0~1kPa...100MPaOutput Signal : 4-20mA, 0-5V, 0-10V, RS485Supply Voltage : 9-24VDC, 3.1-5VProtection Level : Protection Level

• IP68 Waterproof Design: Ensures reliable performance in harsh and submerged environments.
• Hydrostatic Level Measurement: Ideal for precise water depth monitoring in various liquid environments.
• Submersible Pressure Transmitter: Designed for direct immersion in liquids for efficient level sensing.
• 4-20mA RS485 0-10V Output: Provides versatile and accurate signal transmission for industrial applications.
• 316L Stainless Steel Construction: Offers excellent corrosion resistance for long-term durability.
